KOPPACE 170X-1700X Trinocular Metallographic Microscope Light and Dark Field,Polarized DIC Observation 6 inch Large Platform 18 Million Pixels USB Camera

Electronic Amplification:170X-1700X
Optical Magnification:50X、100X、200X、500X
Pixel:18 Million Pixels
Output Method:USB3.0
    Please select the information you wantX
(500 available)
Shipping Cost:
Estimated Delivery Time:
Please select the country you want to ship from
  • Description
  • Reviews
Model KP-MX6R-1800
Electronic Amplification 170X-1700X
Optical Magnification 50X、100X、200X、500X
Optical System Infinity Chromatic Aberration Correction Optical System
Eyepiece High Eye Point large Field of View flat Field Eyepiece PL10X22mm
Objective Lens LMPL-BD Infinite long Working Distance Bright and Dark Field Metallographic Objective
LMPlan 5X/0.15     BD WD 9mm
LMPlan 10X/0.3     BD DIC WD 9mm
LMPlan 20X/0.45   BD DIC WD 3.4mm
LMPlan FLN 50X/0.55 BD WD 7.5mm
Observation Tube Adjustable 5-35° inclination angle Tthree-Way Observation Tube With Infinite Hinge, Interpupillary Distance Adjustment:50-76mm,Unilateral Diopter Adjustment:±5 Diopter,
Objective Lens Converter Bright and Dark Field Five-Hole Converter With DIC Slot
Focusing System Translucent and Reflective Frame,Front low-Hand Position Coarse and Fine Coaxial Focus Adjustment Mechanism.Coarse Adjustment Stroke 33mm,Fine Adjustment Accuracy 0.001mm.With Adjustment Elastic Device to Prevent Sliding and Random Upper limit Device
Operating Platform 6-Inch Three-layer Mechanical Mobile Platform,Low-Hand Position X,Y Direction Coaxial Adjustment,Platform Area 450mm×220mm,Reflected illumination Movement Range:158mm×158mm;Transmission illumination Movement Range:100×100mm,With Clutch Handle,Can Be Used For All Fast Moving Within The Range of Travel,Glass Stage Plate (For Transmission and Reflection)
Upper Lighting System Built-In 100-240V Wide Voltage System,5W Warm Color LED Transmitted Light illumination System,Independent Control of Upper and Lower Light;With Filter Slot and Polarizing Device Slot; With Bright and Dark Field Switching Mechanism,Preset Center,Light Intensity Continuously Adjustable
Under Lighting System Single High-Power 5W Warm Color LED White Light,Continuous Adjustable Light Intensity
Condenser Transmissive Shake-Out Achromatic Condenser (N.A0.9) With Variable Aperture Stop,Center Adjustable
Polarizer Polarizer Insert Plate,360°Rotating Analyzer Insert Plate
Trinocular Interface 0.5X  C-mount Interface
Pixel 18 Million Pixels
Output Method USB3.0
Sensor 18M/Sony Special
Sensor Size 1/2.2"(5.86x4.46)
Resolution Frame Rate 17@4880x3720,40@2448x1836,50@1728x1296
Pixel Size 1.2μmx1.2μm
Exposure Time 0.1ms~15s
Exposure Auto/Manual
White Balance Lock White Balance,Area White Balance,Gray Level
Image Adjustment Hue,Saturation,Brightness,Contrast,Sharpness,Permeability,DPC
Capture Click This Button to Capture The Image of The Preview Interface and Support Continuous Point Photography.
Operating System Microsoft Windows/Vista/7/8/10(32 & 64 bit)OS X (Mac OS X), Linux
File Save Can Set File Name,Save Pictures With Time Format,Save Path Selection
Camera Function Advanced Software For Windows:
- Provide the SDK
- Provides Splicing,EDF,Video Recording and Measurement Functions;
- Perform Measurements of Length,Angle,Radian,Area,Etc;
Packing List 1、A Pair of Eyepieces PL10X/22mm
2、0.5X Trinocular Interface *1
3、Objective lens LMPlan 5X/0.15 BD WD 9mm *1
4、Objective lens LMPlan 10X/0.3 BD DIC WD 9mm *1
5、Objective lens LMPlan 20X/0.45 BD DIC WD3.4mm *1
6、Objective lens LMPlan FLN 50X/0.55 BD WD7.5mm *1
7、Microscope Body *1
8、Light Box Power Cord *1
9、Analyzer *1
10、Polarizer *1
11、6-inch Platform *1
12、LBD Color Balance Film (White Light) *1
13、18 MP USB3.0 Camera *1
14、Measuring Calibration Ruler *1
15、USB3.0 Line *1
16、Software *1
Note 1、This Product Does Not Contain Computer;
2、This Product is Through the USB Interface Connected to the Computer for Use,We Provide Free Professional Image Software;
3、This Product is USB3.0 Interface,It Needs to be Connected to the Computer.
4、This Product Has Upper and Lower Lighting System.
