KOPPACE 170X-1700X Metallurgical Microscope 18 Million Pixels USB3.0 Measurement Camera Support image Mosaic

KP-CX40M-18MP
Electronic Amplification:170X-1700X
Magnification:50X,100X,200X,500X
Eyepiece:PL10X(Φ22mm)
Objective Lens:5X,10X,20X,50X
Price:
$4999.99
    Please select the information you wantX
Quantity:
-
+
(500 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
  • Description
  • Reviews
Model KP-CX40M-18MP
Electronic Amplification  170X-1700X
Optical Magnification 50X、100X、200X、500X
Optical System Infinity Chromatic Aberration Correction Optical System
Eyepiece High Eye Point Large Field of View Flat Field Eyepiece PL10X22mm
Objective Lens Infinity Long Working Distance Flat Field Achromatic Metallographic Objective
PL5X/0.15   WD10.8mm
PL10X/0.3   WD12.2mm
PL20X/0.45 WD4mm
PL50X/0.55  WD7.9mm
Observation Tube 30° Tilt,Inverted Image,Hinged Trinocular Viewing Tube,Pupillary Distance Adjustment Range 54-75mm
Objective Lens Converter Internal Positioning Five-Hole Converter
Focusing System low-Handed Coarse and Micro-Coaxial Focusing Mechanism,Coarse Adjustment Stroke 28mm,Fine Adjustment Accuracy 0.002mm.Adjustable Tensioning Device With Anti-Slip and Random upper limit Device.Up and Down Adjustment Mechanism With Platform Position,Maximum Sample Height 28mm
Operating Platform Double-layer Mechanical Moving Platform,Coaxial Adjustment of X and Y Directions in low hand Position;Platform Size 175mmX145mm,Moving Range:76mmX42mm
Upper Lighting System Built In 100-240V Wide Voltage System,5WLED,Warm Color,Upper Lighting System,Cora illumination,Field of View Resizing,Aperture Size Adjustment,Adjustable Center
Lower Lighting System Built In 100-240V Wide Voltage System,5WLED,Warm Color,Brightness Control.
Condenser Abbe condenser,Numerical Aperture N.A0.9,With Variable aperture Adjustment,Center Adjustable
Polarized Light Device Polarizer and Analyzer
Trinocular Interface Three Eye Interface 0.5X CTV
Pixel 18 Million Pixels
Output Method USB3.0
Sensor 18M/Sony Special
Sensor Size 1/2.2"(5.86x4.46)
Resolution Frame Rate 17@4880x3720,40@2448x1836,50@1728x1296
Pixel Size 1.2μmx1.2μm
Exposure Time 0.1ms~15s
Exposure Auto/Manual
White Balance Lock White Balance,Area White Balance,Gray Level
Image Adjustment Hue,Saturation,Brightness,Contrast,Sharpness,Permeability,DPC
Capture Click This Button to Capture The Image of The Preview Interface and Support Continuous Point Photography.
Operating System Microsoft Windows/Vista/7/8/10(32 & 64 bit)OS X (Mac OS X), Linux
File Save Can Set File Name,Save Pictures With Time Format,Save Path Selection
Camera Function Advanced Software For Windows:
- Provide the SDK
- Provides Splicing,EDF,Video Recording and Measurement Functions;
- Perform Measurements of Length,Angle,Radian,Area,Etc;
Packing List 1. Eyepiece PL10X/22mm One Pair
2. Objective Lens LMPlan 5X * 1
3. Objective Lens LMPlan 10X * 1
4. Objective Lens LMPlan20X * 1
5. Objective Lens LMPlan50X * 1
6. Microscope Body * 1
7. Trinocular Lens * 1
8. Power Cord * 1
9、Polarizer *1
10、Analyzer *1
11、18 MP USB3.0 Camera *1
12、Measuring Calibration Ruler *1
13、USB3.0 Line *1
14、Software *1
Note 1、This Product Does Not Contain Computer;
2、This Product is Through the USB Interface Connected to the Computer for Use,We Provide Free Professional Image Software;
3、This Product is USB3.0 Interface,It Needs to be Connected to the Computer.
4、This Product Has Upper and Lower Lighting System.

****************************************************************************************************************************************************************************************************************************************************
