| Model | KP-6000MSX |
| Measuring Function | Between two Points,Point to line,three point circle,center distance,concentric circle, point to circle,line to circle,parallel line,Rectangle,angle,radian,polygon |
| Pixel | 2 Million Pixels |
| Output Method | HDMI、Network Interface |
| Sensor | 2M/Sony |
| Sensor Size | 1/2＂CMOS |
| Resolution Ratio | 1920X1080 |
| Output Frame Rate | 60FPS |
| Pixel Size | 3.75μmX3.75μm |
| Operating System | LINUX 3.10 |
| Storage Mode | U disk.Can Take Pictures,Measure |
| Image overlay | Can be imported through drawing and display transparent background color on the screen Convenient product and overlay image alignment detection |
| Color Adjustment | R、G、B |
| White Balance | Auto/Manual |
| Exposure | Auto/Manual |
| Mirror Configuration | Horizontal Mirror,Vertical Mirror |
| Reticle lines | 32 Groups Horizontal and vertical lines |
| Image Adjustment | Brightness,Contrast,Saturation,Edge sharpening,anti flicker,HDR suppression of Strong light Modes |
| Network interface | Provide Professional KOPPACE Image Software to support measurement and Photography |
| Camera Interface | C Interface |
| Power Supply | AC100V-240V DC-12V |
| language | Chinese,English,Traditional |
| USB Interface | 2 USB Ports,1 Connected to USB Drive and 1 Connected to Mouse |
| Depth of Field Synthesis | Samples of Different heights can be Combined into a clear picture |
| Packing List |
1. HDMI Camera * 1 |
| Note | 1. This product is an HDMI HD camera that can perform image overlay, depth of field synthesis, and measurement. 2. Connect HDMI to the monitor,Connect the network port to the PC and synchronize the output. 3. This product can be connected to a monitor or computer for measurement. 4. This product is equipped with a measuring calibration ruler. 5. PC cannot achieve image overlay and depth of field synthesis, and HDMI display needs to be connected, |
******************************************************************************************************************
****************************************************************************************************
