KOPPACE 309X-7740X Trinocular Compound Lab Microscope 8.3 Million Pixels 4K Camera

Optical Magnification:40X-1600X
Electronic Amplification:309X-7740X
Pixel:8.3 Million Pixels
Camera Function:U Disk Storage,Photo Taking,Video Recording and Measurement
    Please select the information you wantX
(500 available)
Shipping Cost:
Estimated Delivery Time:
Please select the country you want to ship from
  • Description
  • Reviews
Model KP-PH800
Optical Magnification 40X-1600X
Electronic Amplification 309X-7740X
Observation Tube Hinge Trinocular,30 Degrees Inclined,360 Degrees Rotate
Interpupillary Distance Adjustment Range 48mm-76mm
Eyepiece Wide-angle Eyepiece WF10X/20mm,WF16X/15mm
Objective Lens Infinite Flat Field Achromatic Objective
PIan 4/0.1          PIan 10/0.25   PIan 40/0.65        PIan 100/1.25 oil
Converter Four Holes Conversion
Operating Platform Right Hand Low Hand Control of X and Y Directions Platform Area:160mmX142mm,Moving Range 76mmX52mm
Coarse Micro Focusing Mechanism Low Hand Coarse Micro Coaxial Focusing Mechanism,Coarse Adjustment Stroke 22mm,Fine Adjustment Accuracy 0.002mm
Condenser Abbe Condenser,N.A. = 1.25,Adjustable Center,With Variable Light bar and Filter Bracket
Light Source Reflector Lamp Room,Single High Power 3W LED
Power External Regulated Power Adapter, 100V-250V_AC50/60Hz DC5V/2A
Trinocular Interface 1X
Pixel 8.3 Million Pixels
Output Method HDMI、GigE
Sensor 8.3M/Sony
Sensor Size 1/1.8"CMOS
Resolution Frame Rate 60@3840 X 2160,Photo Resolution 7680 X 4320
Pixel Size 2.0μmx2.0μm
Color Adjustment R/G/B
Exposure Auto/Manual
White Balance LLSingle/Auto/White Balance
Image Adjustment Exposure Value,Saturation,Brightness,Contrast,Definition,Anti Reflective,Black and White,Flip,Crosshair,Support Horizontal/Vertical Flip,Picture Playback
Menu Mouse Operation
Storage Mode U Disk Storage,Photo Taking,Video Recording and Measurement
Camera Function ◆ SONY High-Performance light-Sensitive Chip,Low Noise,High Sensitivity,and True Color;
◆ HD Photography,Video Recording and Measurement;
◆ The Network Port Transmits Images in Real Time,Extends the Migration Algorithm to the PC Host,and Interacts in Real Time;
◆ Support Mouse and Keyboard Operation (Wireless);
◆ Measurement Function:Point Spacing,Point line Spacing,Line Spacing,Circle Center Distance,Arc, Circle,Angle Rectangle and Polygon Measurement,Calibration Function,Automatic Edge Searching.
Packing List 1、Eyepiece  WF10X/20mm *2
2、Eyepiece  WF16X *2
3、Objective Lens 4X *1
4、Objective Lens 10X *1
5、Objective Lens 40X *1
6、Objective Lens 100X *1
7、Trinocular Microscope Body *1
8、1X Trinocular Interface *1
9、Power Adapter *1
10、5 Pieces Specimen *1
11、Dust Cover *1
12、4K Camera  *1
13、HDMI Cable*1
14、Camera Power Adapter  *1
Note: 1、100X (oil mirror),Because We Can Not Deliver liquid Products With Express Delivery,We Will Remove Immersion Oil.
2. This Product Does not Contain a Display;
3. This Product is HDMI/Network Port Output, through the HDMI Cable Directly Connected to the Monitor,or the Network Cable Connected to the Computer For use,The Monitor and Computer can be Output at the Same Time.
4. The Product Has Two USB Ports,One For Connecting the Mouse and one For Connecting the USB Flash Drive.Measurements can be Made Directly on the Display Using the Mouse.Save Images and Excel Dat;
